Characteristics of Various Rubber Plates

Time: 2019-05-17
Summary: Basic Characteristics of Various Rubber Plates
Food grade rubber plates

Specification: 1 ~ 80mm * 100 ~ 2000mm;

Proportion: 1.5;

Tension force: 4Mpa;

Elongation: 300%;

Hardness: 60 [+5];

Performance: non-toxic, tasteless, good elasticity;

Uses: Used in food processing places and food industry tool accessories;

Features: It is made of odorless and non-toxic raw materials. It has no harmful chemical composition to human body, and its color is uniform and pollution-free.

Colour: Red and white; customizable colours as required

Packaging: kraft paper, woven bags, film bags.

Rubber board SBR rubber board

Specification: 1 ~ 100 mm * 100 ~ 2000 mm;

Proportion: 1.4;

Tension force: 5 Mpa;

Elongation: 300%;

Hardness: 50 60;

Performance: It has good wear resistance, elasticity, shear resistance, tear resistance, flexibility, heat resistance, acid and alkali resistance, wear resistance and noise reduction.

Purpose: Pump, valve, cyclone and other liners, grooves, pipes and other liners.

Color: black, Milky white, grey, red, green and other colors;

Rubber board insulating rubber sheet

Specification: 3 ~ 80mm * 100 ~ 2000mm;

Proportion: 1.6;

Tension force: 5 Mpa;

Elongation: 280%;

Hardness: 65 [+5];

Performance: Working in dielectric environment, the maximum insulation voltage is 100,000 volts.

Colour: Black or any other colour;

Packaging: kraft paper, film, woven bags, according to customer requirements fixed length, fixed weight packaging.

Specification of Rubber Plate

edit

Specification Thickness of Rubber Plate 1mm-50mm

Width 0.1m-2m

Long 1 m - - - infinite length

Rubber Board white rubber board

Product Usage: It is suitable for floor, carriage, workbench laying, medical treatment, food processing and so on, which are not required for high quality or one-time use.

Specific gravity: 1.8 + 0.05g/cm & sup3;

Tension: 2.5 MPa,

The elongation is 200%.

Hardness: 70 + 5 ShoreA

Rubber board green rubber board

Product Usage: Suitable for cushioning rings and seals with general product quality requirements.

Specific gravity: 1.6 + 0.05g/cm & sup3;

Tension: 3.0 MPa,

Elongation: 250%.

Hardness: 65 + 5 ShoreA

Rubber plate Red rubber plate

Usage: Suitable for punching gaskets, gaskets and seals.

Specific gravity: 1.5.

Tension: 4.0 MPa,

Elongation: 280%.

Hardness: 65 + 5

Rubber sheet plus rubber sheet

Product Specification: 2-50mm*500-1600mm

Product use: stamping seals, rings, used as light conveyor belts, strong requirements for the environment to work;

Specific gravity: 1.4-1.6 + 0.05g/cm³

Tension: 3.5 MPa,

Elongation: 280%.

Hardness: 65 + 5 ShoreA

Rubber sheet Fabric reinforced rubber sheet

Product Specification: 1-50mm*500-1600mm

Rubber sheet neoprene rubber sheet

Specific gravity: 1.5 + 0.05g/cm & sup3; Breaking force: 3.0MPa, elongation 280%, hardness: 65 + 5ShoreA features: widely used in electronic and thermal aging sites, can be used as oil-resistant materials.

Rubber plate Fine striped rubber plate

Product Specification: Thickness: 3-6mm; Width: 1-1.2m; Length: According to Requirements

Rubber plate with edges

Product Specification: Thickness: 3-20mm; Thickness: 1-1.2mm; Length: According to Requirements

Rubber Plate Coin Rubber Plate

Product Specification: Thickness: 4-6mm: Width: 1.2mm; Length: According to Requirements

Rubber plate with hole cushion rubber plate

Product Specification: 1000*700*18mm, 915*915*15mm

Rubber plate Rubber floor mat Rubber board

Product Specification: Thickness: 15-50mm; Width * Length: 500 * 500mm

Technical parameters: specific gravity: 1.0 + 0.05g/cm & sup3; breaking force: 2.0MPa; elongation: 110%, hardness: 50 + 5 ShoreA

Rubber board corridor pad

Product specifications: 1000*2000*14.5mm, 1000*2000*11mm technical parameters: specific gravity: 1.3+0.05g/cm³ tensile force: 2.0MPa, elongation: 110%, hardness: 50+5 ShoreA

Rubber board orange peel rubber board

Batch Model: Thickness: 3-6mm; Width: 1.2m; Length: According to Requirements

Technical parameters:

Specific gravity: 1.45 + 0.05g/cm & sup3;

Pulling force: 3MPa,

Elongation: 220%.

Hardness: 60 + 5

diamond plate

Product Specification: 1200*1830*12.7mm, 1220*2135*16mm, 1525*2135*10mm

Technical parameters:

Specific gravity: 1.35 + 0.05g/cm & sup3;

Tension: 8.5 MPa,

Elongation: 220%.

Hardness: 55-65 ShoreA

We offer so many types of mats and rubber sheet that we can't list them all on the website, so if you don't see what you are looking for, Please contact us.
